Current Collector Power Frame Drawbar Bracket for Display Applications

Manufactured from high‑strength low‑alloy (HSLA) steel or cast ductile iron (depending on load rating), the bracket features a box‑section design with integral reinforcing gussets and stress‑relief fillets at all high‑load junctions. This construction withstands the extreme torsional loads, shock impacts, and continuous vibration typical of crane runways and conveyor systems, while maintaining precise geometric alignment between the collector arm and the conductor bar. The bracket supports total loads up to 80 kg (collector arm + display + cable bundles) without measurable deflection.

The bracket incorporates a dedicated, reinforced mounting plate – positioned at an ergonomic 15° upward tilt – with multiple hole patterns including:

• VESA 75*75 and 100*100 for standard industrial displays.

• Custom threaded inserts for proprietary display housings.

• Slotted adjustment holes allowing ±10 mm lateral and ±5 mm vertical repositioning of the display for optimal viewing angle.

This platform is isolated from the main collector arm pivot point by a set of elastomeric dampers, reducing high‑frequency vibration transmission to the display and significantly improving screen readability and electronic component longevity.

While designated as a “fixed" bracket, it offers critical fine‑adjustment features:

• Height adjustment – slotted mounting holes and shim packs allow ±15 mm vertical tuning to match the collector shoe engagement height with the conductor bar.

• Lateral centering – a cam‑adjustable pivot bushing permits ±5 mm side‑to‑side movement for precise alignment with the power rail.

• Angular compensation – tapered alignment pins and eccentric locking collars enable ±2° tilt correction to accommodate track unevenness or installation tolerances.

Once set, all adjustments are locked with high‑strength clamping bolts and self‑locking nuts, ensuring zero drift under dynamic loading.

The bracket features built‑in, enclosed cable trunks and segmented clip‑on tie points that route:

• High‑power cables (from the collector output) and sensor leads (voltage taps, temperature sensors) from the collector head to the display.

• Signal and communication cables (RS‑485, Modbus, or 4‑20 mA) from the display to the external control system.

All cable paths are designed with smooth radius bends (≥ 10* cable diameter) to prevent stress and chafing. Grommet‑lined pass‑through holes and snap‑in plastic liners protect cables from sharp edges. An optional hinged cover over the trunking provides additional mechanical and ingress protection (IP54 – IP67 available).

The bracket is hot‑dip galvanised (HDG) as standard, with a minimum zinc coating of 85 μm, providing excellent resistance to moisture, salt spray, and industrial chemicals. For food‑processing, pharmaceutical, or coastal applications, a stainless steel 304/316 variant is offered. A two‑coat epoxy/polyurethane finish (RAL 1023 yellow or RAL 7035 grey) is available for colour‑coding and enhanced chemical resistance.

Despite its heavy‑duty load capacity, the bracket incorporates weight‑reducing cut‑outs and a streamlined profile that minimises the additional burden on the trolley or moving structure. The design is fully analysed using finite element method (FEM) to ensure uniform stress distribution and eliminate weak points.
